EDC132K

Home Product Center Radar Accessories

EDC132K

Matching housing for easy installation

motion detection
serial adjustable

Product Introduction

■Support 0-10V PWM and 5V I/O outputs.■Preserve the infrared receiver, photosensitive holes, and terminal holes■Remote control adjustable working mode, sensing range, time delay and other parameters■With the shell, easy to install

Specification

Frequency band

5.8GHz±75MHz
Input voltage

12V/7-12V
Output voltage

5V (0-10V compatible)
Operating current

18±2mA
Near-gear movement sensing radius

0.5-4m
Mid-range motion sensing radius

2-5.5m
Remote Motion Sensing Radius

3.5-7m
Hanging height

3m
Delay time

Remote control adjustable
Product size

32*24.7*8.5mm

Application Scenarios

Line Lamp

Ceiling Light

Panel Light

Tube
